罗克韦尔AB隔离开关194E-E25-1756

     Allen-Bradley罗克韦尔AB-194E: 负载开关是针对本地电机隔离和隔离开关应用项目而设计的。
这些开关分为 3 极型和 6 极型，带有附加的极、接地和中性线端子以及辅助触点。
这些开关与 Bulletin 194L 控制和负载开关共用相同的操作柄。

特性:
适合用作电机端隔离开关 (UL508)
16、25、32、40、63、80、100 A 感性负载开关
IP66/UL 类型 1/3/3R/12 操作柄
IP2LX 手指保护端子
3 极和 6 极型号；用于形成 4、5、7 和 8 极单元的附加极
正面/门安装或 DIN/基座安装结构
提供断开/接通和切换配置
3 极和 6 极封闭式开关
可选热塑外壳
强制断开动作
提供可锁手柄（多 3 把挂锁）
Catalog Number
Description
Accessories
194E-A100-1753 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 100A, 3 Poles
194E-A16-1753 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 16A, 3 Poles
194E-A16-1756 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 16A, 6 Poles
194E-A25-1753 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 25A, 3 Poles
194E-A25-1753-6N IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 25A, 3 Poles, Supplied with a Type N Red/Yellow Actuator
194E-A25-1756 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 25A, 6 Poles
194E-A32-1753 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 32A, 3 Poles
194E-A32-1753-6N IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 32A, 3 Poles, Supplied with a Type N Red/Yellow Actuator
194E-A32-1756 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 32A, 6 Poles
194E-A40-1753 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 40A, 3 Poles
194E-A40-1756 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 40A, 6 Poles
194E-A63-1753 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 63A, 3 Poles
194E-A63-1753-6N IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 63A, 3 Poles, Supplied with a Type N Red/Yellow Actuator
194E-A63-1756 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 63A, 6 Poles
194E-A80-1753 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 80A, 3 Poles
194E-A80-1756 IEC Load Switch, Open - Base / DIN Rail, OFF-ON 90°, 80A, 6 Poles
194E-E100-1753 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 100A, 3 Poles
194E-E100-1756 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 100A, 6 Poles
194E-E16-1753 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 16A, 3 Poles
194E-E16-1756 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 16A, 6 Poles
194E-E25-1753 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 25A, 3 Poles
194E-E25-1753-6N IEC Load Switch, Open - Front / Door, OFF-ON 90°, 25A, 3 Poles, Supplied with a Type N Red/Yellow Actuator
194E-E25-1756 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 25A, 6 Poles
194E-E32-1753 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 32A, 3 Poles
194E-E32-1753-6N IEC Load Switch, Open - Front / Door, OFF-ON 90°, 32A, 3 Poles, Supplied with a Type N Red/Yellow Actuator
194E-E32-1756 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 32A, 6 Poles
194E-E40-1753 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 40A, 3 Poles
194E-E40-1756 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 40A, 6 Poles
194E-E63-1753 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 63A, 3 Poles
194E-E63-1753-6N IEC Load Switch, Open - Front / Door, OFF-ON 90°, 63A, 3 Poles, Supplied with a Type N Red/Yellow Actuator
194E-E63-1756 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 63A, 6 Poles
194E-E80-1753 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 80A, 3 Poles
194E-E80-1756 IEC Load Switch, Open - Front / Door, OFF-ON 90°, 80A, 6 Poles
194E-FA20 IEC Load Switch, NEMA Type 3/4/12 - IP66 Painted Steel - Base / DIN Rail, 6" x 4" x 5", Handle Color:Grey / Black, 25A, 3 Poles
194E-FA20E IEC Load Switch, NEMA Type 3/4/12 - IP66 Painted Steel - Base / DIN Rail, 6" x 4" x 5", Handle Color:Red / Yellow, 25A, 3 Poles
194E-FA32 IEC Load Switch, NEMA Type 3/4/12 - IP66 Painted Steel - Base / DIN Rail, 6" x 4" x 5", Handle Color:Grey / Black, 32A, 3 Poles
194E-FA32E IEC Load Switch, NEMA Type 3/4/12 - IP66 Painted Steel - Base / DIN Rail, 6" x 4" x 5", Handle Color:Red / Yellow, 32A, 3 Poles
194E-FA40 IEC Load Switch, NEMA Type 3/4/12 - IP66 Painted Steel - Base / DIN Rail, 6" x 4" x 5", Handle Color:Grey / Black, 40A, 3 Poles
194E-FA40E IEC Load Switch, NEMA Type 3/4/12 - IP66 Painted Steel - Base / DIN Rail, 6" x 4" x 5", Handle Color:Red / Yellow, 40A, 3 Poles
194E-KA20 IEC Load Switch, NEMA Type 3/4/4X - IP66 Non-Metallic - Base / DIN Rail, 6" x 4" x 5", Handle Color:Grey / Black, 25A, 3 Poles
194E-KA20E IEC Load Switch, NEMA Type 3/4/4X - IP66 Non-Metallic - Base / DIN Rail, 6" x 4" x 5", Handle Color:Red / Yellow, 25A, 3 Poles
194E-Y16-1753-4N IEC Load Switch, IP65 (Thermoplastic) - Base / DIN Rail, OFF-ON 90°, 16A, 3 Poles, Supplied with a Type N Red/Yellow Actuator
194E-Y25-1753-6N IEC Load Switch, IP65 (Thermoplastic) - Base / DIN Rail, OFF-ON 90°, 25A, 3 Poles, Supplied with a Type N Red/Yellow Actuator
194E-Y25-1756-6N IEC Load Switch, IP65 (Thermoplastic) - Base / DIN Rail, OFF-ON 90°, 25A, 6 Poles, Supplied with a Type N Red/Yellow Actuator
194E-Y32-1753-6N IEC Load Switch, IP65 (Thermoplastic) - Base / DIN Rail, OFF-ON 90°, 32A, 3 Poles, Supplied with a Type N Red/Yellow Actuator
194E-Y40-1753-6N IEC Load Switch, IP65 (Thermoplastic) - Base / DIN Rail, OFF-ON 90°, 40A, 3 Poles, Supplied with a Type N
