23A美国AB接触器100-C23EJ10

罗克韦尔AB接触器：
100-C 在标准接触器中提供节省空间的设计，Bulletin 100-D 通过集成 PLC 接口实现灵活性。Bulletin 100-G 接触器系列对 1200 A (AC3) 到 1350 A (AC1) 的 Bulletin 100 接触器系列提供重要扩展。

特性
符合 IEC、UL 和 CSA 标准要求
提供适合所有接触器尺寸的通用附件
包含可反转线圈端子（进线侧或负载侧）
将开断时间缩短为 18-23ms，比标准的电子线圈缩短了 50%
提供 IP2X 手指保护
符合 RoHs
包含内置浪涌抑制100-C23A01 100-C IEC Contactors, 240V 60Hz , Screw Terminals,

Line Side, 23A, 240V 60Hz, 0 N.O. 1 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23A10 100-C IEC Contactors, 240V 60Hz , Screw Terminals,

Line Side, 23A, 240V 60Hz, 1 N.O. 0 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23B10 100-C IEC Contactors, , Screw Terminals, Line Side,

23A, 440V 50Hz / 480V 60Hz, 1 N.O. 0 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23C10 100-C IEC Contactors, , Screw Terminals, Line Side,

23A, 550V 50Hz / 600V 60Hz, 1 N.O. 0 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23D01 100-C IEC Contactors, , Screw Terminals, Line Side,

23A, 110V 50Hz / 120V 60Hz, 0 N.O. 1 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23D10 100-C IEC Contactors, , Screw Terminals, Line Side,

23A, 110V 50Hz / 120V 60Hz, 1 N.O. 0 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23D200 100-C IEC Contactors, , Screw Terminals, Line Side,

23A, 110V 50Hz / 120V 60Hz, 2 N.O. 2 N.C. Main Contact

Configuration, , Single Pack
100-C23D300 100-C IEC Contactors, , Screw Terminals, Line Side,

23A, 110V 50Hz / 120V 60Hz, 3 N.O. 1 N.C. Main Contact

Configuration, , Single Pack
100-C23D400 100-C IEC Contactors, , Screw Terminals, Line Side,

23A, 110V 50Hz / 120V 60Hz, 4 N.O. 0 N.C. Main Contact

Configuration, , Single Pack
100-C23ED10 100-C IEC Contactors, 110-125V DC Electronic Coil ,

Screw Terminals, Line Side, 23A, 110-130V 50/60Hz / 110-130V DC

Electronic Coil w/ Elec. Interface, 1 N.O. 0 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23EJ01 100-C IEC Contactors, 24V DC Electronic Coil ,

Screw Terminals, Line Side, 23A, 24V DC Electronic Coil w/ Elec.

Interface, 0 N.O. 1 N.C. Auxiliary Contact Configuration, , Single

Pack
100-C23EJ200 100-C IEC Contactors, 24V DC Electronic Coil ,

Screw Terminals, Line Side, 23A, 24V DC Electronic Coil w/ Elec.

Interface, 2 N.O. 2 N.C. Main Contact Configuration, , Single Pack
100-C23EJ300 100-C IEC Contactors, 24V DC Electronic Coil ,

Screw Terminals, Line Side, 23A, 24V DC Electronic Coil w/ Elec.

Interface, 3 N.O. 1 N.C. Main Contact Configuration, , Single Pack
100-C23EJ400 100-C IEC Contactors, 24V DC Electronic Coil ,

Screw Terminals, Line Side, 23A, 24V DC Electronic Coil w/ Elec.

Interface, 4 N.O. 0 N.C. Main Contact Configuration, , Single Pack
100-C23F10 100-C IEC Contactors, 220-230V 50Hz , Screw

Terminals, Line Side, 23A, 220-230V 50Hz, 1 N.O. 0 N.C. Auxiliary

Contact Configuration, , Single Pack
100-C23H10 100-C IEC Contactors, 208V 60Hz , Screw Terminals,

Line Side, 23A, 208V 60Hz, 1 N.O. 0 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23J01 100-C IEC Contactors, 24V 60Hz , Screw Terminals,

Line Side, 23A, 24V 60Hz, 0 N.O. 1 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23J10 100-C IEC Contactors, 24V 60Hz , Screw Terminals,

Line Side, 23A, 24V 60Hz, 1 N.O. 0 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23J400 100-C IEC Contactors, 24V 60Hz , Screw Terminals,

Line Side, 23A, 24V 60Hz, 4 N.O. 0 N.C. Main Contact Configuration,

, Single Pack
100-C23K10 100-C IEC Contactors, 24V 50Hz , Screw Terminals,

Line Side, 23A, 24V 50Hz, 1 N.O. 0 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23KD01 100-C IEC Contactors, 110V 50/60Hz , Screw

Terminals, Line Side, 23A, 110V 50/60Hz, 0 N.O. 1 N.C. Auxiliary

Contact Configuration, , Single Pack
100-C23KD10 100-C IEC Contactors, 110V 50/60Hz , Screw

Terminals, Line Side, 23A, 110V 50/60Hz, 1 N.O. 0 N.C. Auxiliary

Contact Configuration, , Single Pack
100-C23KF10 100-C IEC Contactors, 230V 50/60Hz , Screw

Terminals, Line Side, 23A, 230V 50/60Hz, 1 N.O. 0 N.C. Auxiliary

Contact Configuration, , Single Pack
100-C23KG10 100-C IEC Contactors, , Screw Terminals, Line Side,

23A, 200V 50Hz / 200V 60Hz / 200-220V 60Hz, 1 N.O. 0 N.C. Auxiliary

Contact Configuration, , Single Pack
100-C23KJ10 100-C IEC Contactors, 24V 50/60Hz , Screw

Terminals, Line Side, 23A, 24V 50/60Hz, 1 N.O. 0 N.C. Auxiliary

Contact Configuration, , Single Pack
100-C23KL10 100-C IEC Contactors, , Screw Terminals, Line Side,

23A, 200-230V 50/60Hz, 1 N.O. 0 N.C. Auxiliary Contact

Configuration, , Single Pack
100-C23KP10 100-C IEC Contactors, , Screw Terminals, Line Side,

23A, 100V 50Hz / 100V 50/60Hz / 100-110V 60Hz, 1 N.O. 0 N.C.

Auxiliary Contact Configuration, , Single Pack
100-C23L01 100-C IEC Contactors, 208-240V 60Hz , Screw

Terminals, Line Side, 23A, 200-220V 50Hz / 208-240V 60Hz, 0 N.O. 1

N.C. Auxiliary Contact Configuration, , Single Pack
100-C23L10 100-C IEC Contactors, 208-240V 60Hz , Screw

Terminals, Line Side, 23A, 200-220V 50Hz / 208-240V 60Hz, 1 N.O. 0

N.C. Auxiliary Contact Configuration, , Single Pack
100-C23UD10 100-C IEC Contactors, , Screw Terminals, Load Side,

23A, 110V 50Hz / 120V 60Hz, 1 N.O. 0 N.C. Auxiliary Contact

Configuration, , Single Pack
